"2 PORE STEEL T" pH electrode
Steel body, with temperature sensor
"2 PORE STEEL T" pH electrode combined with temperature sensor NTC
- With fixed cable plug BNC + Cinch 1m
- Steel body
- Dimensions (LXØ) 50x6 mm
- Filled polymer, maintenance-free
- Thanks to 6 mm tip is ideal for meats
- For penetration measurements.
Specifications
| Range pH |
0 ÷ 14 pH |
| Range temperature |
-10 ÷ +60°C |
| Body material |
Glass/steel |
| Head |
Fix cable / BNC |
| Temperature probe |
With temperature sensor NTC
30KΩ plug RCA Cinch |
| Diaphragm |
2 open pore diaphragms |
| Reference system |
Ag Coated |
| Electrolyte |
Polymer maintenance free |
| End length |
50 mm |
| Diameter |
Body Ø 12 mm / Tip Ø 6 mm |
XS Sensor series
A complete line laboratory pH, Redox and conductivity electrodes, with glass and plastic body.
The new XS sensor are available with S7 head or cable fix with BNC or DIN connector plug.
For food application many models are equipped with temperature sensor inside for fast temperature compensation. Some models are designed to help in daily work in GLP condition with indelible internal serial number and certificate are provided with quality test.
Special polymer electrolyte combined with high performance reference system generate a complete range of electrodes for food application in special part of this section.
Blue inner buffer provides clear visual of contact with internal pH glass membrane. All XS sensors line are connectable at all common pHmeters brand in the market.
Our customer support are available for every special application request or support for right type electrode indication.
XS sensor for pH is not only pH electrode is perfect combination for pH measurement with XS pH meters and XS buffer solutions.
