Bottles "pressure plus+" plastic coated DR Series

Pressure resistance conforms to DIN EN 1595

Graduated bottles for high pressure/vacuum applications plastic coated.

The coating provides scratch, leak and splinter protection and is ideally suited to both the transport and storage of hazardous media or valuable samples.

With easy-to-read scale and large labelling field for easy marking, in fired-on, highly durable ceramic.

Pressure resistance conforms to DIN EN 1595, confirmed by GS marking (TÜV ID: 0000020716)
Vacuum and/or pressure resistant from – 1 bar to + 1.5 bar due to modified geometry (based on ISO 4796-1)
When pressure loaded the following apply: thermal shock resistance 30 K and maximum usage temperature + 140 °C
Blue scale for visual differentiation from the standard laboratory bottle
Typical applications: safe working under pressure or vacuum, sampling under pressure, storage of gas generating media

Technical specifications

Code	Capacity (ml)	DIN GL	Ø (mm)	h (mm)	Qty
DR/218152402	100	45	56	100	10
DR/117592500	250	45	70	138	10
DR/117592600	500	45	86	176	10
DR/218155408	1.000	45	101	225	10

N.B. Foreign import product: if not immediately available in stock, estimated delivery time in 30 days
