LEGATO 185 SYRINGE PUMP
Single Syringe, programmable touch screen, picoliter infusion/withdrawal pump
Single syringe infuse/withdraw optimized for low flow with program options for 2 programs. 50 steps each.
Accommodates syringes 0.5 µl to 60 ml. User definable flow rates with selectable target volume or time values to control the total infusion volume.
- The Legato 185 has a finer lead screw and a different pulley ratio from the Legato 101/111. It offers multi step programs, each with 50 steps
- The large touchscreen display allow sthe user to see all of the pumps operating parameters to ensure proper operation during the experiments
- Syringe size and flow rate are easily displayed as well as the volume delivered and the elapsed time. Set up is easy using the icon driven software
The Legato 185 is an infuse/withdraw syringe pump. It accommodates one syringe from 0.5 ul to 10 ml. Any type of syringe can be used in the
unit including glass, plastic and stainless steel.
The syringe is held in place by KD Scientifics' new clamping mechanism designed to hold syringes securely in place.
The run screen has all of the pump parameters, as well as, the pumps
running conditions. The basic pump offers the same easy to use touch screen configuration and "run" screen as the more advanced Legato 200.
An led light on the front panel makes it easy to see if the pump is running. Syringe size and flow rates are easily displayed as well as the volume delivered and the elapsed time.
The pump is versatile and can be connected through the RS485 interface. Advanced micro stepping techniques are employed to further reduce the step angle to eliminate flow pulsation.
Features
- Holds one syringe from 0.5 µl to 60 ml
- High resolution color touch screen
- Unparalleled ease of use
- Touch pad "lock" feature
- LED light on front panel
- Full metal chassis
- Built in syringe table
- Up to 30 lb linear force
- Advanced microstepping techniques
- Built in RS485 interface
- USB port
- I/O & TTL interface
- Continuous mode of operation
- Spill dam
- Programmable
Specifications
| Accuracy |
|
| Reproducibility |
|
| Syringes (Min/Max) |
|
| Flow Rate |
- Minimum (0.5 µl syringe): 0.54 pl/min
- Maximum (60 ml syringe): 39 ml/min
|
| Display |
- 4.3 WQVGA TFT Color Display with Touchpad
|
| Non-Volatile Memory |
|
| Connectors |
- RS485 - IEEE-1394 6 pos
- USB - Type B
- I/O & TTL - 15 pin D-Sub Connector
|
| Linear Force (Max) |
- 13.6 kg (30 ls) @ 100% Force Selection
|
| Drive Motor |
|
| Motor Drive Control |
- Microprocessor with 1/16 microstepping
|
Number of Microsteps
per one rev.of Lead Screw |
|
| Step Revolution |
|
| Step Rate - Minimum |
|
| Step Rate - Maximum |
|
| Pusher Travel Rate - Minimum |
|
| Pusher Travel Rate - Maximum |
|
| Power |
- 100-240 VAC: 50/60 Hz, 50 W, 0.5 A fuse
|
| Dimensions |
- 22.6 x 19.05 x 15 cm (9 x 7.5 x 5 in)
|
| Weight |
|
| Operating Temperature |
- 4 degree C to 40 degree C (40 degree F to 104 degree F)
|
| Storage Temperature |
- -10 degree C to 70 degree C (14 degree F to 158 degree F)
|
| Humidity |
- 20% to 80% RH non condensing
|
| Mode of Operation |
|
| Classification |
|
| Pollution Degree |
|
| Installation Category |
|
| Regulatory Certification |
- CE, UL, CSA, CB Scheme, EU RoHS
|
