Sonicator 600 W / 20÷500 ml

Supplied with probe Ø 16 mm and support, software, temperature probe

Ultrasonic Processor FS/000600/N

In the complete configuration that includes the Ø 16 mm probe with support,  the temperature probe and the PC use software.

Supplied

  • Ultrasonic disintegrator FS/000600/N
  • Probe Ø 16 mm (range 20÷500 ml) *
  • Probe support
  • Temperature probe
  • Software

* Also available Ø 13 (10÷300 ml)  and Ø 18 mm  (50÷1.500 ml) optional probes

Major Function

  • Auto-tuning for convenience of use and optimal processing efficiency
  • 99h total working time controller, 1s – 99h, count-down time display
  • Working time can be displayed as aggregate number
  • On/off impulse timer: make sure to deal with temperature sensitive sample. On and off can be set from 1s to 99min
  • Automatic amplitude compensation to make the amplitude not changed following the carring.
  • All the function can be displayed in the large LCD screen , operation easy, Fully microprocessor controlled and completely programmable.
  • Configure : temperature probe , temperature display and protection when the temperature is over limition

Common applications

  • Mixing, blending, emulsifying, and processing solutions
  • Reducing particle size of suspensions
  • Dispersing suspensions
  • Disrupting cells
  • Catalyzing chemical reaction

Technical parameters

  • Model: FS/000600N
  • Output Power: 600W
  • Net weight: 4.5Kg
  • Frequency: 20KHz
  • Timer: LED 1s – 99 hours adjustable
  • Power adjustable: 0%--100%,
  • Impulse : number closed loop, open loop: set:1s-99min
  • Piezoelectric frequency energy converter: CV33,
  • Lead zirconate titanate (PZT) pyroelectric ceramics
  • Converter dimensions: Diameter:73 mm / Length:170 mm / Weight: 870 g Length of cable: 150 cm
  • Standard probe: titanium alloy material TI-6AL-4V
  • Diameter(probe): 16 mm (can also choose 8/10/12/13/18 mm)
  • Processing volume: 20÷500 ml
  • Total length:139 mm
  • weight: 400 g
  • Temperture sensor:0--300°C
  • Power Supply: 220 V 50 Hz
