3-place manifold, 47mm, stainless steel
Complete filtration station with stainless steel base
Stainless steel filter holder manifold with 3 positions.
This manifold allows simultaneous vacuum filtration of 3 samples.
It must be configured with glass, plastic or stainless steel filter holders with standard perforated caps n° 8.
The manifold is connected to a single vacuum source and each filtering station is equipped with a tap that allows its independent use.
Technical specifications
| Codice |
MK/XX/25047/35 |
| Number of workstations |
3 |
| Materials |
- Stainless steel body, three-way valves and filter holder supports
- Anodized aluminium knobs
- Hose connector and cap in stainless steel |
| Filter holder supports |
Filter holder supports accept No. 8 silicone perforated stopper |
| Dimensions |
45,1×15,2×15,2 cm |
| Weight |
5 kg |
| Sterilization |
Autoclave at 121°C |
