| Code |
PK/0T710P |
| Description |
Measure pH value of high purity water in power, petrochemical and other industries. |
| Display |
7-inch capacitive touch screen with resolution 1024*600 |
| pH |
| Measurement range |
(-2.00÷19.99) pH |
| Resolution |
0.1/0.01 pH |
| Accuracy |
±0.02 pH |
| Input current |
≤1×10-12 A |
| Input impedance |
≥1×1012 Ω |
| Stability |
±0.01 pH/3h |
| Temperature compensation |
(0÷ 100)℃ (auto or manual ) |
| mV |
| Range (mV/ORP/EH) |
-1999.9mV ÷ +1999.9mV |
| Resolution |
0.1 mV |
| Accuracy |
±0.03% FS |
| Temperature |
| Range |
-10℃ ÷ +110℃ |
| Resolution |
0.1℃ |
| Accuracy |
±0.5℃ |
| Calibration |
| Automatic (1, 2, 3 points) / Europe & USA, NIST / China standards |
| Others |
| Storage |
1000 sets |
| Power |
DC12V/1A |
| Communication interface |
USB(A), USB(B) , Wireless Bluetooth module |
| Dimensions / weight |
240×170×70mm/600g |
| Working Conditions |
| Temperature |
15÷30 ℃ |
| Humidity |
≤85% |
| IP grade |
IP54 |
