Straight connectors tapered (PP)
Polypropylene, autoclavable, excellent chemical and temperature resistance
Straight connectors tapered, polypropylene (PP)
- Excellent chemical and temperature resistance
- With serrations to hold hoses tightly and prevent slipping
- Autoclavable
Hoses connectors - Features
- Autoclavable, they meet with the food and drug regulations, 90/128/CEE, 92/39/CEE and FDA 21 CFR 177.1520
- Dimensions are shown as both nominal and exact as elasticity of hoses will influence the choice of size
- Use hoses selector (art. KT/001759) to determine "grip"
- This will then give equivalent crest dimension for the particular connector concerned
Suitable for foodstuff
To order
| Code |
Nominal O.D. (mm) |
Crest O.D.(mm) |
Bore Ø (mm) |
Qty |
| KT/000510 |
4/5/6 |
3/4,5/5,5 |
2 |
100 |
| KT/000511 |
6/7/8 |
4,5/7,/8,2 |
3,5 |
100 |
| KT/000512 |
8/9/10 |
6,3/9/11 |
4,5 |
100 |
| KT/000513 |
10/11/12 |
8,3/10,5/13 |
6,5 |
100 |
| KT/000514 |
12/13/14 |
10/13/15 |
8,5 |
100 |
| KT/000515 |
14/15/16 |
12/14,5/17 |
10,5 |
100 |
